Order Lithium Tantalate (LiTaO3) for SAW Filters
UniversityWafer supplies lithium tantalate wafers and crystals for SAW filters, resonators, and piezoelectric device research. The cut, propagation direction, surface quality, and device stack influence measured performance. Share your target frequency, wafer size, and polishing requirements to identify a suitable starting substrate.
LiTaO3 Wafer Options to Request
- 36° Y-cut lithium tantalate: A commonly studied cut for SAW filter and resonator fabrication.
- 42° Y-cut lithium tantalate: Another SAW orientation with different coupling, velocity, and temperature trade-offs; compare measured designs before choosing.
- X-, Y-, and Z-cut crystals: Ask about these orientations for specialized piezoelectric or electro-optic experiments.
- Thin-film LiTaO3 structures: Specify a film, bonding stack, or suspended membrane separately if your project requires a bulk acoustic resonator rather than a conventional SAW wafer.
Specifications for a Useful RF Wafer Quote
- Crystal cut and acoustic propagation direction, such as 36° Y-X or 42° Y-X.
- Wafer diameter or diced dimensions, substrate thickness, and quantity.
- Single-side-polished (SSP) or double-side-polished (DSP) finish and any surface roughness requirement.
- Any composition, electrode process, flat or notch requirement, and tolerance that matters to your design.
- Whether you need a bulk crystal wafer or a specified bonded wafer stack.
For a broader comparison of SAW substrate materials, review lithium tantalate alongside lithium niobate and quartz. Availability and test data for a requested cut or finish should be confirmed with the quote.
Get Your Quote FAST! Or, Browse Available Wafers and start researching today!
Why Lithium Tantalate Works for SAW RF Filters
Lithium tantalate (LiTaO3) is a piezoelectric crystal used as a substrate for surface acoustic wave (SAW) filters and RF resonators. A patterned electrode converts an electrical signal into an acoustic wave that travels along the crystal surface. Crystal orientation influences the wave mode, acoustic velocity, electromechanical coupling, and temperature drift. The finished filter's insertion loss and selectivity also depend on electrode dimensions, layout, and packaging.
Key LiTaO3 Properties for Filter Design
Begin substrate selection with the measurements required by your design rather than treating one crystal cut as best for every frequency band. Useful parameters include:
- Electromechanical coupling: Describes conversion between electrical and acoustic energy; it affects possible filter bandwidth.
- Acoustic phase velocity: Influences the wavelength and electrode pitch required for a target center frequency.
- Temperature coefficient of frequency (TCF): Describes how resonance frequency changes as operating temperature changes. It is separate from long-term aging.
- Acoustic attenuation and resonator quality factor: Influence loss and selectivity alongside electrode and packaging effects.
- Wafer surface and thickness: Affect lithography, handling, and compatibility with a proposed device stack.
The material's measured behavior depends on composition as well as orientation. For example, a published experimental comparison of lithium tantalate SAW filters reported distinct TCF results for 36° and 42° Y-cut crystals and for different lithium compositions. Use your own device requirements and measured data when selecting a wafer.
36° vs. 42° Y-Cut Lithium Tantalate Wafers
36° Y-cut LiTaO3 and 42° Y-cut LiTaO3 are both used in SAW research. Specify the propagation direction along with the cut: an orientation such as 36° Y-X describes more than the angle alone. A change in cut can affect wave velocity, coupling, propagation loss, and temperature response.
- 36° Y-X: A common reference point for SAW filters; evaluate the measured coupling, frequency drift, and acoustic mode in your target band.
- 42° Y-X: Offers a different trade-off between coupling, velocity, and drift. It does not automatically give a lower absolute TCF than 36° Y-X.
- Other orientations: X-, Y-, and Z-cut crystals may serve different acoustic or optical experiments. Confirm the intended wave mode before substituting one for a SAW-specific cut.
See the LiTaO3 RF properties guide for background on piezoelectric response and crystal orientation. Confirm actual cut tolerances, composition, and availability with the substrate quote.
SAW Filters and Thin-Film Lithium Tantalate Resonators
Conventional SAW filters use interdigital transducers (IDTs) on a piezoelectric wafer to launch waves along its surface. A polished bulk LiTaO3 wafer is a starting substrate for this fabrication approach. The acoustic mode and response depend on the cut, propagation direction, metal pattern, and surrounding layers.
Designing a LiTaO3 SAW Filter
Define a target center frequency, passband, acceptable insertion loss, and operating temperature range before choosing the wafer. IDT pitch is closely tied to acoustic wavelength; the number of fingers, aperture, metal thickness, and reflector layout affect other parts of the response. Compare these choices through simulation and a fabricated test structure. The SAW device integration guide discusses related substrate, electrode, and packaging considerations.
How BAW-Style Research Differs
Researchers also study laterally excited bulk acoustic resonators using thin-film lithium tantalate in a bonded or suspended stack. Such a device needs a specified film thickness and supporting structure; it is not interchangeable with a full-thickness SAW wafer. If your research calls for a bulk acoustic resonator, supply a cross-section showing the LiTaO3 film, supporting layers, and electrodes. Explore wafer bonding when the required structure uses layered substrates.
Electrode Geometry, Insertion Loss, and Bandwidth
A wafer alone does not determine RF filter performance. Once a crystal cut is selected, review these design variables together:
- IDT finger pitch: Sets the acoustic wavelength and strongly influences center frequency.
- Finger count and aperture: Affect transducer response, loss, and the effective interaction region.
- Metallization thickness and material: Can change mass loading, resistance, and power handling.
- Reflectors and resonator layout: Shape passband, stopband, and unwanted-mode behavior.
- Bond pads and packaging: Add parasitic effects that matter when evaluating a complete RF device.
Compare simulated frequency response with measured S-parameters from prototypes. For GHz devices, include electrical parasitics alongside acoustic behavior instead of attributing every shift or loss to the lithium tantalate wafer.
Temperature Drift and Substrate Stacks
For an RF filter that operates across a wide temperature range, characterize its TCF on the completed device. Crystal cut matters, but composition, electrode design, overlays, bonded layers, and packaging stress can all change the result. A 42° Y-cut wafer should not be described as a universal temperature-compensated replacement for a 36° Y-cut wafer.
Some research uses SiO2 overlays or engineered bonded wafers to modify acoustic confinement and thermal response. Those methods require device-specific modeling and process-compatible materials. State whether you need an uncoated bulk crystal, an oxide overlay for your own processing, or a specified layered structure when requesting a quote.
Power Handling and Device Testing
Power handling and linearity are properties of a finished RF device. A high Curie temperature or a polished wafer does not by itself establish safe operating power. Test electrode heating, acoustic nonlinearity, substrate mounting, and packaging under the intended input power and ambient conditions.
Measured insertion loss, center frequency, bandwidth, and out-of-band rejection help refine a prototype. If a design is sensitive to wafer variation, include cut tolerance, surface roughness, thickness variation, and any requested wafer-level characterization in the procurement specification.
Applications and Ordering Checklist
Lithium tantalate wafer applications include wireless RF front-end research, acoustic resonators, piezoelectric sensors, and specialized integrated devices. Suitability for any particular mobile or industrial band must be validated on the fabricated filter.
- Specify the target SAW frequency band and anticipated device process.
- Provide crystal cut, wave propagation direction, and any composition requirement.
- List diameter or diced size, thickness, polishing, surface tolerance, and quantity.
- Identify whether the request is for a bulk SAW wafer or a custom thin-film stack.
- Ask which measurements and material documentation are available for the proposed lot.
Use the quote form to discuss lithium tantalate substrates for SAW filters, or browse available research wafers online.
