Aluminum Gallium Nitride (AlGaN)

university wafer substrates

AlNGaN Substrates for Lamps, Lasers and LEDs

A Sr. Consulting Scientist requested a quote for the following.

Can you get (or do you have) sapphire wafers with AlGaN coating for sale?

I need something around 1 cm diameter or a bit larger.  Thickness:  200 – 500 um, nominally.

UniversityWafer, Inc. Quoted:

Item   Qty.   Description
DA18. 3/5   AlGaN Epi on Sapphire wafers,
Substrate: Sapphire[A] wafers, P/P50.8±0.3mmØ×430±25µm,
PrimaryFlat Orientation C-plane±0.2°; 16.0±1.0mm
Both sides Epi ready polished,
Front Surface Epi-polished, Ra < 0.3 nm (by AFM);
Back Surface Epi-polished, Ra < 0.3 nm(by AFM) ;
EPI Layer: undoped Al0.3GaN:-[100], 1um thick.

Reference #164039 for pricing.

Get Your AlGaN Quote FAST! Or, Buy Online and Start Researching Today!





CAPTCHA Image

Undoped C-Plane AlGaN Template

A graduate student requested a quote for the following:

I am interested in 2" diameter c-plane AlGaN template, undoped. Please quote me for qty <5 of 50% AlGaN.  Also, please provide specs on dislocation density, surface roughness, substrate miscut, polish.  I generally prefer single-side polished wafers.

Reference #194822 for specs and pricing.



AlGaN/GaN Heterostructures Deposited on Al2O3 by MOVPE

A PhD candidate requested a quote for the following:

Can you offer me any of the following wafers?

  • Al2O3 2" SSP, 375-400 umvarious AlGaN devices, including light-emitting diodes (LEDs), laser diodes, and high-electron-mobility transistors (HEMTs).
  • SiC 4H 2", 375-400 um (insulating for transistor manufacturing)
  • Si (111) 2", 375-400 um (high resistivity also for transistor)

We are going to use them to transfer our HFET technology that is based on AlGaN/GaN heterostructures deposited on Al2O3 by MOVPE method. I thought that 4H SiC is better for GaN-based transistor applications, at least so I have been told. But on the other hand we need semi-insulating substrate, so it does not influence transistor operation at high fields and frequencies.

Reference #171068 for specs and pricing.

P-Type AlGaN Template

A postdoc needed help with this research and requested a quote for the following:

Price for p-type GaN template and p-type AlGaN template including detailed technical data of those.

I need p-type GaN (may be doped with magnesium) and p-type AlGaN substrate. It can be deposited on sapphire wafer or quartz wafer, thickness is around 0.3 to 0.8 micron. I preferred a square substrate than a round one, substrate must have at least 1000oC of melting point. I also need a full technical data of these substrate: electrical, optical, mechanical and surface properties, thickness of film and wafer etc.

If you only have a round substrate, I'll buy 1 spec each.
If you have square substrate, please give me it's parameters.

Reference #197858 for specs and pricing.

Research Grade AlGaN Substrates

A sales engineer requested a quote for the following:

We need a 2" templates 200-300nm thick AlGaN layer on c-plane sapphire. The AlGaN layer should be doped with  a Si concentration of 3-5e18 1/cm3.  The aim is for 2 Al compositions of 20% and 40%. What is the price for each research grade 2" wafer?

UniversityWafer, Inc. Quoted:

Substrate Dia Buffer layer Epitaxial/Dopant Thickness
sapphire 2" 50 nm AlN GaN, intrinsic 100 nm
sapphire 2" 50 nm AlN GaN, intrinsic 300 nm
sapphire 2" 50 nm AlN Al10%GaN,  intrinsic 300 nm
sapphire 2" 50 nm AlN Al20%GaN,  N/Si 250 nm
sapphire 2" 50 nm AlN Al40%GaN,  N/Si 250 nm

Reference #102784 for specs and pricing.
