Silicon Wafers for Anisotropic Etching

Anisotropic silicon etching removes silicon at different rates along different crystal planes, creating cavities, V-grooves, membranes, and other micromachined structures. For KOH and TMAH wet etching, wafer selection depends on crystal orientation, thickness, doping, surface finish, and mask compatibility. UniversityWafer supplies undoped silicon wafers, double-side-polished silicon wafers, and silicon nitride coated substrates for MEMS and silicon micromachining research.

UW Logo

Undoped and DSP Silicon Wafers for Wet Etching

For anisotropic wet etching, start with the geometry and etch depth your device requires. (100) silicon wafers are commonly selected for cavities and V-grooves bounded by slowly etched {111} planes. Double-side-polished (DSP) silicon provides polished front and back surfaces for processes that require patterning or alignment on both sides.

Undoped silicon substrates are an option when intentional dopants are unnecessary. Lightly doped silicon can also be suitable. Specify the dopant and resistivity required by your device rather than assuming every anisotropic etching process needs undoped material.

Example Research Request

“Can you quote 25 pieces of 4-inch DSP (100) silicon with 100 nm low-stress silicon nitride? Please also quote 25 undoped bare DSP (100) silicon wafers and the same wafers with a 100 nm low-stress silicon nitride coating.”

Example Wafer Specifications

  • Substrate: Undoped single-crystal silicon
  • Diameter: 4-inch / 100 mm wafer format
  • Orientation: (100)
  • Surface finish: Double-side polished
  • Film option: 100 nm low-stress silicon nitride
  • Coated sides: Specify one or both sides
  • Thickness and resistivity: Specify with your request
  • Intended process: KOH or TMAH anisotropic etching
  • Reference: #123402

These specifications describe an example inquiry. Confirm wafer dimensions, coating requirements, and film compatibility with your etch process when requesting a quote.

Request an Anisotropic Etching Wafer Quote

Include wafer diameter, thickness, orientation, dopant, resistivity, quantity, and surface finish. For coated wafers, add nitride thickness, deposition method, film stress, and coating side. Mention your etchant and target etch depth so the substrate requirements can be reviewed.

Get Your Quote Fast! Or Buy Silicon Wafers Online and start researching today.





How Anisotropic Silicon Etching Works

Anisotropic etching of silicon wafers In anisotropic wet etching, the silicon removal rate depends on crystallographic orientation. Potassium hydroxide (KOH) and tetramethylammonium hydroxide (TMAH) are commonly used for this process. Mask openings expose selected regions while the surrounding film protects the wafer surface.

On a (100) wafer, slowly etched {111} planes can form sidewalls at approximately 54.7° to the wafer surface. Mask alignment, opening dimensions, and etch depth determine the resulting cavity or groove geometry. This relationship is central to designing silicon wafer structures for bulk micromachining.

KOH and TMAH Etching: Wafer Selection

Both etchants require attention to wafer orientation, mask durability, bath conditions, and device materials. A wafer suitable for one recipe may need a different film thickness or mask configuration for another. See the KOH and TMAH anisotropic wet etching guide for additional process context.

KOH Etching Substrates

KOH etching is used to create crystallographic cavities, grooves, and membrane windows in silicon. Silicon nitride coated wafers are commonly considered when a durable masking film is needed. Match the film composition and thickness to the planned etch duration and conditions.

TMAH Silicon Etching Substrates

TMAH also supports crystallographic silicon etching. Specify the wafer orientation, doping, and masking film for your recipe. Etch rate and surface finish depend on process conditions, including temperature, concentration, and any additives. Do not assume a KOH process and a TMAH process produce identical results.

Anisotropic silicon etching with a silicon nitride mask for MEMS sensors and microfluidic channels

Compare Silicon Substrates and Etch Mask Options

Substrate choices for anisotropic silicon wet etching
Wafer or Film Why Select It? What to Specify
(100) silicon Common starting orientation for angled-wall cavities and V-grooves. Orientation tolerance, mask alignment, thickness, and target geometry.
DSP silicon Polished surfaces on both sides for front/back processing. Surface finish, thickness variation, and alignment requirements.
Undoped silicon or lightly doped silicon Options when a heavily doped etch-stop region is unnecessary. Dopant, resistivity, and electrical requirements.
Low-stress nitride on silicon Masking or membrane option where film stress matters. Deposition method, film composition, stress, thickness, and coated sides.
Heavily boron-doped silicon Can provide dopant-dependent etch-stop behavior in suitable processes. Boron concentration, layer depth, and etchant compatibility.

Low-Stress Silicon Nitride Masks for Anisotropic Etching

Silicon nitride can protect selected silicon regions during wet etching and can remain as a suspended membrane after the underlying silicon is removed. For silicon nitride membrane fabrication, film stress affects mechanical behavior, while mask integrity affects the ability to withstand the full etch.

The label low-stress silicon nitride alone does not establish etch resistance. LPCVD and PECVD films can differ in composition, density, stress, and etch rate. Review these properties when choosing between stoichiometric LPCVD silicon nitride and low-stress and super low-stress nitride wafers. A 100 nm film is an example specification, rather than a universal mask thickness.

How Boron Doping Affects Silicon Etch Stops

Heavily boron-doped silicon (p++) can etch much more slowly than lightly doped silicon under suitable wet etching conditions. This behavior can be useful for defining a remaining silicon layer or membrane. Its effectiveness depends on dopant concentration and the selected chemistry.

Ordinary p-type silicon should not automatically be treated as an etch stop. When the design requires etching through the wafer, identify any heavily doped regions that could affect the process. When an etch stop is intentional, specify the doped layer characteristics and target remaining thickness.

Does Undoped Silicon Always Etch Better?

No. Undoped silicon avoids an intentionally introduced dopant, but it does not guarantee smoother surfaces or more uniform etch rates. Crystal quality, mask defects, temperature, concentration, agitation, and process control also affect results. Choose undoped silicon wafers when their material and electrical properties fit your device.

MEMS and Microfluidic Applications

When selecting microfluidic substrates, match the wafer orientation, thickness, and surface finish to your channel design and fabrication process.

  • Pressure sensor diaphragms: Backside cavities that leave a thin sensing region.
  • Microfluidic channels: Crystallographic grooves and fluid-handling cavities.
  • Silicon nitride membranes: Windows formed by removing silicon beneath a masking or structural film.
  • Optical alignment structures: V-grooves and related features defined by crystal planes.
  • MEMS bulk micromachining: Cavities, openings, and support structures designed around wafer geometry.

For membrane and micromachining projects, explore silicon nitride wafers for MEMS fabrication. Specify the substrate and film together so both meet the mechanical and processing needs of the device.

Frequently Asked Questions

Why are (100) wafers used for anisotropic etching?

Their crystallographic relationship with slowly etched {111} planes enables predictable angled-wall cavities and grooves. The final shape depends on mask orientation and dimensions.

Do I need double-side-polished silicon?

DSP silicon wafers are useful when both surfaces require lithography, alignment, or a polished finish. Single-side-polished wafers may be suitable when only one polished surface is needed.

What controls the time needed to etch through silicon?

Wafer thickness and the etch rate under the actual process conditions determine the approximate duration. Use a qualified recipe and measured process data rather than a universal rate.

What should I include in a wafer quote request?

Provide diameter, thickness, orientation, dopant, resistivity, surface finish, quantity, and any coating requirements. Include your etchant, target depth, and membrane requirements when relevant. Request an anisotropic etching wafer quote using the form on this page.
