What are Annealed Silicon Wafers?

In the case of silicon wafers, annealing is often used to improve the surface roughness and crystal quality of the wafer. It can also be used to remove defects and impurities from the surface of the wafer.

There are several different methods that can be used to anneal silicon wafers, including rapid thermal annealing (RTA), furnace annealing, and laser annealing. The specific method used will depend on the desired properties of the annealed wafer and the equipment available.

Annealed silicon wafers are used in a variety of applications, including the production of microelectronic devices, such as transistors and integrated circuits (ICs). They are also used as a substrate for the growth of thin films and as a starting material for the production of other silicon-based materials. In addition to these applications, annealed silicon wafers are also used in research and development for a variety of other applications.

Silicon Wafer Annealing uses a high-temperature furnace to relieves stress in silicon. The heat activates ion-implanted dopants, reduces structural defects and stress, and reduces interface charge at the silicon-silicon dioxide interface.

Silicon wafer annealing is used for the following purposes:

• Relieve stress in silicon wafers
• Activate or move dopants
• Densify deposited or grown films
• Repair implant damage in wafer processing
• Change film to film or film to substrate interfaces for wafers with multiple films
• Silicon on Insulator
• Bonded wafers
