Silicon Density and Wafers for Semiconductor Research
The density of silicon at room temperature is approximately 2.329 g/cm³, equivalent to 2,329 kg/m³. Silicon mass density is used in wafer mass calculations, semiconductor process modeling, mechanical simulations, thermal analysis, and materials characterization.
Silicon Density and Material Properties
- Density in g/cm³: Approximately 2.329
- Density in kg/m³: Approximately 2,329
- Crystal structure: Diamond cubic
- Atomic number: 14
- Atomic mass: 28.085 u
- Melting point: Approximately 1,414°C
UniversityWafer supplies silicon wafers for semiconductor devices, integrated circuits, photovoltaics, MEMS fabrication, photonics, sensors, microfluidics, and university research. Selecting a substrate involves matching its dimensions, electrical properties, and surface finish to the fabrication process.
Request a Silicon Wafer Quote
Tell us the wafer diameter, thickness, crystal orientation, conductivity type, resistivity, surface finish, quantity, and any required films or processing. Include whether you need double-side-polished silicon, undoped silicon substrates, or coated wafers so we can help identify a suitable option for your experiment or device fabrication process.
Get Your Silicon Wafer Quote FAST! Or, Buy Silicon Wafers Online and start researching today!
Silicon Wafer Specifications to Include
- Diameter: 2 inch, 3 inch, 4 inch, 5 inch, 6 inch, 8 inch, or 12 inch
- Crystal orientation: (100), (111), or another required wafer surface orientation
- Conductivity: P-type, N-type, or undoped silicon
- Dopant: Boron, phosphorus, arsenic, antimony, or no intentional doping
- Resistivity: Specify the required range in ohm-centimeters (Ω·cm)
- Thickness: Standard, thin, ultra-thin, or custom, with the required tolerance
- Surface finish: Single-side polished, double-side polished, or unpolished
- Additional layers: Thermal oxide, silicon nitride, silicon epitaxy, or other deposited films
Silicon Substrate and Wafer Options
Researchers may require different silicon wafer grades, surface finishes, and layer structures depending on the application. UniversityWafer provides:
- Prime- and test-grade silicon wafers for research and semiconductor processing
- Silicon-on-insulator (SOI) wafers for MEMS, RF, photonics, and device isolation
- Epitaxial silicon wafers for controlled device-layer thickness and doping
- Thermal oxide silicon wafers for insulation, masking, bonding, and device fabrication
- DSP silicon wafers for bonding, optics, MEMS, and double-sided processing
- High-resistivity silicon wafers for RF, microwave, detector, and photonic applications
How to Calculate Silicon Wafer Mass from Density
Silicon density connects a substrate's volume to its mass: mass = density × volume. For a bare circular wafer, an approximate mass can be calculated from its wafer diameter and wafer thickness. Keep units consistent: density in g/cm³ requires volume in cm³ to obtain mass in grams.
Example: Mass of a 200 mm Silicon Wafer
For an 8-inch (200 mm) silicon wafer with a thickness of 725 µm, the radius is 10 cm and the thickness is 0.0725 cm. Approximating the wafer as a solid cylinder gives volume = π × (10 cm)² × 0.0725 cm ≈ 22.78 cm³. Multiplying by 2.329 g/cm³ gives an approximate bare-wafer mass of 53.0 g. Actual mass can differ with diameter and thickness tolerances, edge geometry, and coatings. Compare silicon wafer diameters and typical thicknesses when estimating another size.
Wafer thickness and diameter therefore affect total mass even when the silicon material density remains approximately the same. Coatings and additional layers should be accounted for separately when estimating the mass of oxide-coated wafers or other layered substrates.
Silicon Density in MEMS and Sensor Design
Density is especially important in MEMS engineering, where the mass of a silicon structure can influence resonant frequency, acceleration sensitivity, and mechanical response. Engineers use material density together with device geometry and mechanical properties to model membranes, cantilevers, sensors, and other microfabricated components.
For structures formed by wet etching, explore anisotropic silicon etching substrates. For devices that require a defined silicon layer above an insulating layer, consider SOI substrates.
What Is the Density of Silicon?
The density of crystalline silicon is approximately 2.329 g/cm³, equivalent to 2,329 kg/m³, at approximately 20°C. Silicon mass density describes how much mass is contained within a given volume of the material. It is used in silicon wafer mass calculations, semiconductor engineering, and mechanical modeling.Silicon density reflects both its atomic mass and its diamond cubic crystal structure. Each silicon atom bonds with four neighboring atoms. The arrangement and spacing of these atoms determine how much mass occupies a given crystal volume.
Physical Properties Related to Silicon Density
| Property | Approximate Value |
|---|---|
| Mass density at approximately 20°C | 2.329 g/cm³ (2,329 kg/m³) |
| Crystal structure | Diamond cubic |
| Atomic number | 14 |
| Atomic mass | 28.085 u |
| Melting point | 1,414°C |
| Thermal conductivity near room temperature | Approximately 149 W/(m·K); varies with material and conditions |
How Silicon Crystal Structure Determines Density
Silicon atoms form a regular three-dimensional lattice. Atomic mass and the volume occupied by the crystal's unit cell determine the material's density. The silicon lattice constant describes the unit-cell dimensions and connects the atomic arrangement to the bulk material.
Density is one of several properties considered when selecting semiconductor silicon wafers. Electrical properties such as silicon resistivity, along with wafer thickness, surface finish, and crystal orientation, also help determine substrate suitability.
Why Silicon Density Matters in Semiconductor Engineering
Silicon density converts a known material volume into mass. It supports wafer mass estimates and simulations where mass, inertia, or volumetric heat capacity matters. These calculations also require appropriate geometry and other material properties.
- Silicon ingot and wafer mass estimates
- Mass calculations after wafer grinding and thinning
- Mechanical and dynamic finite element analysis (FEA)
- MEMS sensor and structural design
- Thermal simulations using density and specific heat capacity
- Mechanical modeling of semiconductor packages and components
Density alone does not describe how a structure bends or conducts heat. Mechanical simulations may also require Young's modulus of silicon, while thermal models require properties such as thermal conductivity and specific heat capacity.
Review the mechanical properties of silicon when selecting material data for structural simulations and device design.
Does Silicon Density Change with Temperature?
Yes. As solid silicon expands with increasing temperature, its mass occupies a larger volume, so its density generally decreases. Use a density value appropriate to the operating temperature when a room-temperature approximation does not provide sufficient accuracy.
Temperature-dependent material properties are relevant to semiconductor processing, thermal analysis, and precision device design. Density should be considered alongside thermal expansion and the other properties required by the model.
Silicon Density Compared with Other Semiconductor Materials
The table compares approximate bulk material densities. For layered substrates, such as GaN on sapphire or silicon-on-insulator wafers, calculate the mass of each layer separately.
| Material | Density (g/cm³) | Typical Applications |
|---|---|---|
| Silicon (Si) | 2.33 | Integrated circuits, MEMS, solar cells |
| Germanium (Ge) | 5.32 | Infrared optics and detectors |
| Gallium arsenide (GaAs) | 5.32 | RF electronics and lasers |
| Silicon carbide (SiC) | 3.21 | Power electronics |
| Gallium nitride (GaN) | 6.15 | LEDs and RF devices |
These are approximate material values. The GaN entry describes the GaN material itself, rather than the effective density of a complete GaN-on-sapphire wafer.
Silicon Applications Where Density Enters the Design
- Wafer mass estimates for semiconductor manufacturing
- MEMS sensors with suspended masses, membranes, or cantilevers
- Mechanical response and resonant-frequency modeling
- Thermal modeling of integrated circuits and power devices
- Material mass estimates for photovoltaic and photonic structures
- University research into silicon material properties
Research Wafers for Silicon Material Characterization
UniversityWafer supplies silicon research wafers, SOI wafers, epitaxial silicon wafers, thermal oxide coated wafers, and custom substrates for materials characterization, semiconductor process development, and device prototyping. For mass estimates in a specific wafer format, review 200 mm silicon wafer specifications.
For experiments requiring polished surfaces on both sides, consider double-side-polished silicon wafers. If intentional doping is unnecessary, explore undoped silicon substrates. Include wafer dimensions, resistivity, orientation, and coating requirements when requesting a quote.
