Clients use our silicon wafers for microfluidics. Below is just one example:
The wafers are used as substrates for SU-8 masks for microfluidics and microcontact stamping tools for bioengineering.
Item# 452 Silicon 100mm P /B <100> 0-100 500um SSP
Get Your Quote FAST!
What the instruction video for all you need to know.
Research clients have used the following wfers for their lab work.
Si Item #478 - 100mm Mechanical Grade Silicon
A university research at a Biomolecular research lab.
We want to buy some specifically-designed silicon wafers from you company. Specifically, we want to have highly n-doped silicon wafer (thickness 0.5mm, very low resistivity) as substrate, and on top of this substrate, we need an extra 5 micron thick silicon epitaxial layer with a resistivity of 5 to 10 Ω-cm. I think your company can make such wafers (please correct me if not). If so, we would like to receive a quote. Also, we want to know whether you company can do ion implantation for silicon wafers to make them n-type or p-type. Looking forward to your reply.
UniversityWafer, Inc. Quoted:
Diameter 100mm
Substrate
n-type silicon wafer as substrate (resistivity, .001-.005 Ohm-cm)
epitaxial layer
n-type silicon wafer 5 to 10 Ω-cm 5um
